Harley® Screamin' Eagle® OE factory spark plugs
• 0.4mm Iridium Tipped Laser Welded Fine Wire Center Electrode
• Tapered Cut U-Groove Ground Electrode Increases Ignitability and Decreases Quenching
• Machine Rolled Threads Prevent Seizing or Cross Threading During Installation and Removal
• 100% Pre-Fired to Assure the Highest Quality Possible
• Purified Alumina Powder Insulator Provides Exceptional Strength and Thermal Conductivity
• Five Rib Insulator Prevents Flashover
• Copper-Glass Seal Bonds Center Electrode and Insulator for a Gas-Tight Seal
Plug Specifications
Thread Size: 12mm
Hex Size: 5/8" (16mm)
Reach: 19mm (3/4")
Seat Type: Gasket
Gap: .036" (0.9mm)
Heat Range: 22
Terminal Type: Removable Nut
Resistor: Yes
Brand: Denso
Center Electrode
Type: Fine Wire
Material: Iridium
Size: 0.4mm
Ground Electrode
Type: Taper Cut
Material: Nickel
Quantity: 1
