ENDURANCE BEEHIVE SPRING KIT

ENDURANCE TC 05-17, XL 04-17, XR 1200 09-17

$359.95
In stock
1105

ENDURANCE BEEHIVE VALVE SPRINGS TC 05-17, XL 04-22, XR 1200 09-13

  • FEULING ENDURANCE BEEHIVE valve springs allow up to 650 lift camshafts no spring seat machining required. Machined from a premium grade Hi-tensile chrome silicon single conical ovate wire, shot-peened with a specially processed thermal heat treat and super NexTex finish to give these valve springs the needed fatigue life to exceed the high demands of V-Twin engines from stock to performance.

    Dont get stung by inferior valve springs!
    Quicker Revving - Smoother Motion - Light Weight Ti Retainers

    FEULING BEEHIVE valve spring kits are each hand measured and labeled specifically based on their coil bind / required open height. Our kits require you to measure installed height and may require use of included shims. This is so you can set up the springs specifically to your camshaft lift for quieter and smoother performance. Similar to tuning your suspension to your weight and riding style.

    FEULING BEEHIVE valve springs use a much smaller and lighter weight retainer which drastically reduces the valve weight creating a much quicker revving and smoother motion than comparable dual valve springs.
    FEULING Endurance springs allow up to 650 cam lift no machining or rocker box clearancing required.
    Eliminate valve spring separation, maximize stability, reduce valve-train noise & harmonics!
    Available for 5/16 and 7mm valves

    Kits include: FEULING ENDURACE BEEHIVE valve springs, lightweight 7 Degree Titanium heat treated retainers, machined spring seats, seat shims, valve locks and a set of premium Viton valve seals equipped with a spring loaded valve stem wiper system.

    SEAT Lbs. / INSTALLED HEIGHT
    198 Lbs. @ 1.685 (0.535 Lift)
    194 Lbs. @ 1.703 (0.553 Lift)
    190 Lbs. @ 1.724 (0.574 Lift)
    187 Lbs. @ 1.754 (0.604 Lift)
    185 Lbs. @ 1.780 (0.630 Lift)
    160 Lbs @ 1.800 (0.650 Lift)
    375 Lbs @ 1.150 OPEN HEIGHT
    Coil Bind @ 1.100


    FITS:

    Twin Cam 05-17, XL 04-22, XR 1200 09-13, 7 Degree, 7mm valve stem with stock triple keeper groove - Includes Springs, Ti Retainers, Seats, Seals, Keepers, seat shims


    COUNTRY OF ORIGIN:

    USA

    Disclaimer: Qualified Manufacturer Declared Replacement Part means any aftermarket part intended to replace an original equipment emissions related part and which is functionally identical to the original equipment part in all respects which in any way affect emissions (including durability), or a consolidated part, that has been evaluated and declared by the manufacturer to meet this definition and carry this categorization and designation label. This manufacturer has declared in writing that it has documentation, based upon sound engineering judgment, indicating the replacement part does not reduce the effectiveness of any required emission control device and it does not cause the modified vehicle/engine/equipment to exceed applicable emissions standards for that make/model/year fitment(s) advertised.

  • Our Dealers / Distributors Part #
    J&P Cycles 420-312
    Drag Specialties 0926-0852
    Neo Factory 017225
    Parts Canada Development Co 0926-0852
    Parts Europe 0926-0852
    Rollies Speed Shop FE-1105
    Sundance Enterprises 1105
    Tucker Rocky - Bikers Choice 481848

  • Make Model Year
    Harley-Davidson 1200 Custom EFI XLC 2004 - 2019
    Harley-Davidson 1200 Custom XLC 2004 - 2006
    Harley-Davidson 1200 Low EFI XLL 2006 - 2011
    Harley-Davidson 1200 Low XLL 2006
    Harley-Davidson 1200 Nightster XLN 2007 - 2012
    Harley-Davidson 1200 Roadster EFI XLR 2006 - 2008
    Harley-Davidson 1200 Roadster XLCX 2016 - 2020
    Harley-Davidson 1200 Roadster XLR 2004 - 2006
    Harley-Davidson 1200 XLCP 2011 - 2017
    Harley-Davidson 15th Anniversary Fat Boy FLSTF 2005
    Harley-Davidson 883 Custom EFI XLC 2004 - 2009
    Harley-Davidson 883 Custom XLC 2004 - 2006
    Harley-Davidson 883 EFI XL 2007 - 2009
    Harley-Davidson 883 Low EFI XLL 2006 - 2010
    Harley-Davidson 883 Low XLL 2005 - 2006
    Harley-Davidson 883 Roadster EFI XLR 2005 - 2007
    Harley-Davidson 883 Roadster XLR 2005 - 2007
    Harley-Davidson 883 SuperLow XLL 2011 - 2019
    Harley-Davidson 883 XL 2004 - 2006
    Harley-Davidson Blackline FXS 2011 - 2013
    Harley-Davidson Breakout FXSB 2013 - 2017
    Harley-Davidson Electra Glide Classic EFI FLHTCI 2002 - 2013
    Harley-Davidson Electra Glide Classic FLHTC 2005
    Harley-Davidson Electra Glide Standard EFI FLHTI 2005 - 2006
    Harley-Davidson Electra Glide Standard FLHT 2005 - 2006
    Harley-Davidson Electra Glide Ultra Classic EFI FLHTCUI 2007 - 2016
    Harley-Davidson Electra Glide Ultra Classic Low FLHTCUL 2015 - 2016
    Harley-Davidson Electra Glide Ultra Limited FLHTK 2010 - 2016
    Harley-Davidson Electra Glide Ultra Limited Low FLHTKL 2015 - 2016
    Harley-Davidson Fat Bob FXDF 2008 - 2017
    Harley-Davidson Fat Boy Lo FLSTFB 2010 - 2016
    Harley-Davidson Forty-Eight Special XLXS 2018 - 2019
    Harley-Davidson Forty-Eight XLX 2010 - 2020
    Harley-Davidson Freewheeler FLRT 2015 - 2016
    Harley-Davidson Iron 1200 XLNS 2018 - 2020
    Harley-Davidson Iron 883 XLN 2009 - 2020
    Harley-Davidson Low Rider EFI FXDL 2007 - 2017
    Harley-Davidson Low Rider FXDL 2005
    Harley-Davidson Road Glide Custom FLTRX 2010 - 2016
    Harley-Davidson Road Glide EFI FLTR 2005 - 2009
    Harley-Davidson Road Glide Special FLTRXS 2015 - 2016
    Harley-Davidson Road Glide Ultra FLTRU 2011 - 2016
    Harley-Davidson Road King Classic EFI FLHRC 2005 - 2006
    Harley-Davidson Road King Custom EFI FLHRS 2005 - 2007
    Harley-Davidson Road King Custom FLHRS 2005 - 2006
    Harley-Davidson Road King EFI FLHR 2007 - 2016
    Harley-Davidson Road King FLHR 2005 - 2006
    Harley-Davidson Seventy-Two XLV 2012 - 2016
    Harley-Davidson Softail Cross Bones FLSTSB 2008 - 2011
    Harley-Davidson Softail Custom EFI FXSTC 2007 - 2010
    Harley-Davidson Softail Deluxe EFI FLSTNI 2005 - 2017
    Harley-Davidson Softail Deluxe FLSTN 2005 - 2006
    Harley-Davidson Softail Deuce EFI FXSTDI 2005 - 2007
    Harley-Davidson Softail Deuce FXSTD 2005 - 2006
    Harley-Davidson Softail Fat Boy EFI FLSTFI 2005 - 2017
    Harley-Davidson Softail Fat Boy FLSTF 2005 - 2006
    Harley-Davidson Softail Heritage Classic EFI FLSTCI 2005 - 2017
    Harley-Davidson Softail Heritage Classic FLSTC 2005 - 2006
    Harley-Davidson Softail Heritage EFI FLSTI 2006
    Harley-Davidson Softail Heritage FLST 2006
    Harley-Davidson Softail Night Train EFI FXSTBI 2005 - 2009
    Harley-Davidson Softail Night Train FXSTB 2005 - 2006
    Harley-Davidson Softail Rocker C FXCWC 2008 - 2011
    Harley-Davidson Softail Rocker FXCW 2008 - 2009
    Harley-Davidson Softail Slim FLS 2012 - 2017
    Harley-Davidson Softail Springer Classic EFI FLSTSCI 2005 - 2007
    Harley-Davidson Softail Springer Classic FLSTSC 2005 - 2006
    Harley-Davidson Softail Springer EFI FXSTSI 2005 - 2006
    Harley-Davidson Softail Springer FXSTS 2005 - 2006
    Harley-Davidson Softail Standard EFI FXSTI 2005 - 2007
    Harley-Davidson Softail Standard FXST 2005 - 2006
    Harley-Davidson Sportster 1200 X XR 2009 - 2012
    Harley-Davidson Sportster 1200 XL 50 2007
    Harley-Davidson Sportster 1200 XR 2009 - 2012
    Harley-Davidson Street Bob FXDB 2006 - 2017
    Harley-Davidson Street Glide EFI FLHX 2006 - 2016
    Harley-Davidson Street Glide FLHX 2006
    Harley-Davidson Street Glide Special FLHXS 2014 - 2016
    Harley-Davidson Street Glide Trike FLHXXX 2010 - 2011
    Harley-Davidson Super Glide Custom EFI FXDCI 2005 - 2014
    Harley-Davidson Super Glide Custom FXDC 2005
    Harley-Davidson Super Glide EFI FXDI 2005 - 2010
    Harley-Davidson Super Glide FXD 2005
    Harley-Davidson Super Glide FXD35 2006
    Harley-Davidson Super Glide Sport EFI FXDXI 2005
    Harley-Davidson Super Glide Sport FXDX 2005
    Harley-Davidson SuperLow 1200 XLT 2014 - 2017
    Harley-Davidson Switchback FLD 2012 - 2016
    Harley-Davidson Tri Glide Ultra Classic FLHTCUTG 2009 - 2016
    Harley-Davidson Wide Glide EFI FXDWGI 2005 - 2017
    Harley-Davidson Wide Glide FXDWG 2005
